EM100 Mini Inverter
48
F02.21 VS Input Bias 2
VS Input Bias 1~ VS Input Bias
3
% 75.0 
F02.22 VS Input Bias 3 VS Input Bias 2～100.0 % 100.0 
F02.23 IS Output Bias 0 -100.0～100.0 % 0.0 
F02.24 IS Output Bias 1 -100.0～100.0 % 25.0 
F02.25 IS Output Bias 2 -100.0～100.0 % 75.0 
F02.26 IS Output Bias 3 -100.0～100.0 % 100.0 
F02.27 IS Input Bias 0 0.0～IS Input Bias 1 % 20.0 
F02.28 IS Input Bias 1 IS Input Bias 0~ IS Input Bias 2 % 40.0 
F02.29 IS Input Bias 2 IS Input Bias 1~ IS Input Bias 3 % 80.0 
F02.30 IS Input Bias 3 IS Input Bias 2～100.0 % 100.0 
F03 Group：Output Terminal Parameter
F03.00
Multi-function
Output Y1
0: Inverter is running
1: Frequency reach signal(FAR)
2: Output Frequency range detection
（FDT)
3: Reverse running
4: Frequency reached upper limit
5: Frequency reached lower limit
6: Inverter fault
7: Inverter is ready to work
8: Overheating prealarm
0
〇
F03.01 Relay Output R1 6
〇
F03.02
Analog Output
M0
0: Output frequency
1: Input command frequency
2: Output current
3: Output voltage
4: VS
5: IS
6: +10V (2mA MAX.)
7: DC bus voltage
0
〇
F03.03
M0 Output
Lower Limit
0.00～100.00
%0.00 
F03.04
M0 Output
Upper Limit
0.00～100.00
%100.00 
F03.05 M0 Output Gain
0.00～300.00
%100.00 
