TECHNICAL CHARACTERISTICS
Table 3-1 (continued)
Item Metric
Imperial
Performance
Rated platform capacity 230 kg
507 lb
Maximum load capacity of extending platform 120 kg
265 lb
Maximum number of occupants (indoor/
outdoor)
2 persons/1 person
Drive speed (stowed)
0～4 km/h
0～2.5 mph
Drive speed (raised)
0～0.5 km/h
0～0.3 mph
Platform lifting time (unloaded)
25～30 s
Platform lowering time (unloaded)
25～30 s
Gradeability (2WD)
25%
Maximum allowable inclination (front-rear/
left-right)
3°/1.5°
Turning radius (inside/outside)
0 m/1.62 m 0 ft/5 ft 3.78 in
Tire size (diameter×width/type)
323×100 mm/solid 12.7×4 in/solid
Maximum operating noise level
72 dB
IP rating
IP 54
Maximum total vibration on the platform
2.5 m/s²
Maximum whole body vibration value (WBV)
0.5 m/s²
Power
Drive x steer 2 WD × 2 WS
Battery specifications (voltage, capacity,
discharge time) – lead-acid battery
24 V, 220 Ah, 20 hr
System voltage
24 VDC
Control voltage
24 VDC
Charger (input voltage/output current)
100 - 240 V AC/30 A
Drive motor (voltage/power) – AC
24 V /0.6 kW
Weight
Gross weight (indoor/outdoor) 1600 kg
3527 lb
Ground bearing data
Maximum tire load
700 kg
1543 lb
Ground pressure
1230 kPa
178 psi
Environment
Maximum allowable lateral force (indoor/
outdoor)
400 N/200 N 90 lbf/45 lbf
Maximum allowable wind speed (indoor/
outdoor)
0 m/s/12.5 m/s
0 mph/28 mph
