6 SCISSOR ARMS COMPONENTS
Fig. 1 Diagram of Scissor Arms Components
Table 6-1
A. Electric actuator upper end installation (including weighing sensor, bearing, gasket, bolt and nut)
B. Electric actuator lower end installation (including pivot pin, bolt and nut)
1. Lift electric actuator 2. Safety arm 3. Scissor arm assembly fasteners
4. Pivot pin
A
B
B
1
2
3
4
