Sinoboom 0608ME - Chassis Component; Travel Drive and Steering Device

0608ME All Maintenance Manual 33
© Jan. 2024
7 CHASSIS COMPONENT
7.1 TRAVEL DRIVE AND
STEERING DEVICE
Fig. 1 Diagram of Travel Drive and Steering Device
Table 7-1
1. Front tire
2. Drive motor & reducer
3. Right wheel carrier
4. Left wheel carrier 5. Steering connecting rod 6. Steering electric actuator
7. Bearing housing 8. Wheel disc 9. Rear tire
4
3
6
5
2
1
7
8
9
