PLATFORM COMPONENTS
2. Remove the platform controller from the platform.
3. Mark and disconnect the harness connections on
the platform assembly.
4. Use suitable lifting equipment to support the work
platform.
5. Remove the mounting fasteners from the platform
wear pad fixed end.
6. With the assistance of the lifting equipment, slowly
lift the platform slightly and push the platform so that
the wear pad at the mobile end gets to the chute
notch at the bottom of the platform.
7. Slowly remove the platform assembly with the aid of
the lifting equipment.
Installation
For installation, follow the disassembly procedure in re-
verse order.
5.3 PLATFORM EXTENSION
Disassembly
1. Extend the platform appropriately, and ensure that
the platform extension is effectively supported.
2. Use suitable lifting equipment to support the work
platform.
3. Remove the mounting screws on the 4 pulley sup-
ports of the platform assembly.
4. Remove the pulley supports.
5. With the assistance of lifting equipment, slowly re-
move the platform extension from the platform
assembly.
Installation
For installation, follow the disassembly procedure in re-
verse order.
