TECHNICAL CHARACTERISTICS
0608ME All Maintenance Manual 15
© Jan. 2024
3.4 WEIGHT OF MAJOR
COMPONENTS
• Never attempt to move heavy components
without the assistance of mechanical
equipment.
• Never place heavy components at an unstable
position.
Table 3-8
Component Metric (kg) Imperial (lb)
Chassis assembly
1207 2661
Scissor arms assembly
433 955
Platform assembly
232 511
Solid tire 12 49
Drive reducer 37 82
Left chassis door 42 93
Right chassis door
31 68
Wheel carrier 16 35
Steering electric actuator
15 33
Lift electric actuator
75 165
Maintenance-free AGM battery (cell)
32 71
Lead-acid battery (cell)
28 62
Note: The weight of certain components will vary with the machine’s option configuration.
3.5 TORQUE SPECIFICATIONS
Special Torque Requirements
Please refer to the table below for special torque
requirements:
Table 3-9 Special torque requirements
No.
Description Torque value
1
Tire mounting bolt 126 Nm (93 ft-lb)
2
Drive reducer mounting bolt 51 Nm (37.6 ft-lb)
3
Rear wheel bearing housing fastening nut 126 Nm (93 ft-lb)
4
Pivot pin connecting steering electric actuator
with steering connecting rod
230 Nm (169.5 ft-lb)
5
Cable fastening nut M8 9 – 11 Nm (6.6 – 8.1 ft-lb)
6
Cable fastening nut M10 18 – 23 Nm (13.2 – 17 ft-lb)
