© Jan. 2024
58 0608ME All Maintenance Manual
CONTROL SYSTEM
Updating the Program
Updating the program will restore the system
parameters set by the original owner/user/
Sinoboom to the original parameters set by the
control system manufacturer. Updating the
program without prior authorization from
Sinoboom is strictly forbidden. Please contact
SINOBOOM after-sales personnel if you wish to
update the program.
1. Prepare a 4-32 GB USB flash drive in FAT32 file
system format.
2. Upload the ECU program to the root directory of the
USB flash drive: ECU_MAIN.bin.
Note: Please contact Sinoboom after-sales person-
nel if you wish to obtain the program.
3. Turn off the machine, and insert the USB flash drive
into the program updating port (protected by a rub-
ber plug) at the back of ECU.
4. Press and hold the Esc key on the ECU panel while
powering on the machine. Release the Esc key
5 sec after power-on; the program will be updated
automatically.
5. After the program is updated, power off the
machine.
Checking the Program Version
After entering the ECU menu selection mode, select
and the System Settings interface, then select System
Version to identify the current program version.
Query Interface
In the Query Interface, users can query GPS informa-
tion, PCU information, battery pack information, Curtis
driver information and fault code information (for fault
code causes and solutions please refer to Fault Codes
section).
Brake Release
Only electric models are equipped with a brake release
function.
1. Place the machine on solid level ground and secure
the wheels with chocks to prevent the machine from
moving inadvertently.
2. Make sure that the machine is in stowed without
loose or unsecured objects, and there are no people
or tools in the platform and no obstacles in the sur-
rounding area.
3. Enter the ECU menu selection mode, then select
and enter the “Brake Release” interface and press
the Enter key for 5 sec.
Fig. 3
4. The buzzer will sound, and the message “Brake Is
Released” will be shown on the display, indicating
that the brakes have been released successfully.
Fig. 4
5. The machine can now be towed or dragged by ex-
ternal force.
6. Return to the main interface through the Esc key,
and power off the machine as needed. The setting
will reset automatically after power-off and restart.
User Selection Setting
• Users can select the applicable country, driver and
model of the machine in the User Selection menu of
Parameter Debugging.
• The parameters (weight, height, level gauge and joy-
stick) of the machine can be calibrated in the User
Selection menu of Parameter Debugging.
• The lithium battery of the machine can be configured
(if necessary) in the User Selection menu of Parame-
ter Debugging.
Country Selection
1. After entering the ECU menu selection mode, select
and enter the Country Selection interface, press
PgUp key or PgDn key until the desired country is
displayed, and press the Enter key for confirmation.
2. Select one country to open the corresponding con-
figurations for the country. See the table below for
the configurations for each country.
Item China Korea
Japan
EU
US &
Australia
Abroad
Outdoor mode
ON (depend
on models)
ON ON ON ON ON
