Fig. 8
4. The platform will raise and lower twice automati-
cally: it will raise to the highest position and lower
to the stowed position.
5. Once the screen displays “No-load Calibration
Complete “, the no-load calibration was
successful.
Fig. 9
6. Return to the Weight Calibration interface
through the Esc key.
• Full-load calibration
1. Place heavy objects on the platform that have the
same weight as the rated load of the machine.
2. Select and enter the Full-load calibration inter-
face, then press the Enter key to start automatic
calibration.
Fig. 10
3. The platform will raise and lower twice automati-
cally: it will raise to the highest position and lower
to the stowed position.
4. When the screen displays “Full-load calibration
complete! “, the full-load calibration was
successful.
Fig. 11
5. Return to the main interface through the Esc key,
and power off the machine as needed.
Height Calibration
1. Lower the platform to the stowed position. Make
sure there is sufficient overhead space to allow the
platform to be lifted to the maximum height safely.
2. Make sure that no heavy objects are placed on the
platform.
3. Enter the ECU menu selection mode, then select
and enter the Calibrate Height interface and press
the Enter key.
Fig. 12
4. The platform will automatically raise to the highest
position, and then lower to the stowed position.
5. When the screen displays “Height Calibration
Done”, the height calibration was successful.
Fig. 13
6. Return to the main interface through the Esc key,
lower the platform to the stowed position, and power
off the machine as needed.
Parameters Setting
Modifying the options in the parameter settings
(including alarm parameters, functional
configurations, speed parameters, and alarm
settings, etc.)) must be carried out only by
authorized and qualified personnel who have
undergone professional training by Sinoboom.
Not meeting this requirement bears significant
risks.
Warning Parameters
In the Warning Parameters menu of Parameter Debug-
ging, the following parameters can be set: level gauge
X-axis warning, level gauge Y-axis warning, raised/
stowed shift point, allowable overload lowering height,
low speed limit height, low voltage pre-alarm value, low
voltage alarm value, outdoor height limit value, low volt-
age alarm time, standby time, drive motor current limit,
pump motor current limit, deceleration time 1, decelera-
tion time 2 and motor serial number.
Note:
• The input angle setting value needs to be multiplied
by 10. For example, if the input value is 20, the ac-
tual angle value is 2°.
• The height setting value is in decimeter (dm).
• The input voltage setting value needs to be multi-
plied by 10. For example, if the input value is 20, the
actual voltage value is 2 volts (V).
No-load calibration
complete
Full-load calibration
complete
