11 CONTROL SYSTEM
All operations in this section must be performed
by authorized and qualified personnel who have
undergone professional training by Sinoboom.
Not meeting this requirement bears significant
risk.
Unsafe Operation Hazard
• The machine has been pro-
grammed before delivery. It’s for-
bidden to modify the system
settings and/or update the soft-
ware without authorization from
Sinoboom.
Due to different machine configu-
rations, certain descriptions be-
low may not apply to your
machine. If questions arise during
operation of the machine in ac-
cordance with the manual please
hold the operation and contact Si-
noboom after sales personnel in
time.
• Not operating the machine prop-
erly may result in death, serious
injury or machine damage.
NOTICE
PCU, ECU, sensors, etc. are precisely adjusted and
have received protective treatment before delivery.
Therefore, persons who have not been professionally
trained and authorized by Sinoboom may not
disassemble the respective housings, otherwise
moisture and dust ingress may affect proper
functioning of these devices.
11.1 SINOBOOM MAIN CONTROL
SYSTEM
This section is applicable to machines configured with
Sinoboom main control system and right chassis door
with wide panel.
System Interface
Pull out the emergency stop button at the ground con-
trols to the ON position and turn the key switch to
ground control position. Press the Enter key on the main
interface of the ground controls to enter the ECU menu
selection mode. Select and enter different function inter-
faces by pressing the PgUp /PgDn keys. The system in-
terface is described in the figure below:
Note: some interfaces can only be accessed with a
password (the password can only be provided to per-
sonnel professionally trained and authorized by
Sinoboom).
