CONTROL SYSTEM
Fig. 1 System interface
ECU
main interface
Query Interface
Language
setting
System Version
Passive Car
Lock setting
Communication
setting
Bootloader
Brake release
Switching value
input check
Switching value
output check
Analog value input check
Analog value output check
PWM output check
Double-axis inclination
check
Set value
CarID
Trouble code
inquiry
GPS Information
Service
PCU Information
Service
Battery pack
information query
Curtis Driver
Information
Keyswitch Voltage
Battery Current
Pump Current
Leftmotor_Current
Rightmotor_Current
Battery capacity
Leftmotor_Speed
Rightmotor_Speed
Controller_Temperature
Leftmotor_Temperature
Rightmotor_Temperature
Bus timing
output
GPS fault
Pulse 0.5Hz
Auto locked
once
SIM lost once
GPS state
GPS offline time
Password
ICCID
PCU version
number
4G version
number
Battery cell
voltage highest
Battery cell
voltage lowest
Battery
temperature highst
Battery
temperature lowest
Total battery
voltage
Total battery
current
SOC
No of charge
cycles
No of discharge
cycles
Leftmotor_actualspeed
Rightmotor_actualspeed
Receive_liftcode
Left motor brake state
Right motor brake state
Left motor error
Right motor error
Left Ver
Right Ver
See the
next page
User Name
Unlock
vehicle
User
settings
IO
functional test
Parameter
debugging
K relay
InDoor/OutDoor
Mod
Time setting
PCU version number
