TECHNICAL CHARACTERISTICS
3.3 SPECIFICATIONS OF MAJOR
COMPONENTS
Drive Reducer
Table 3-3 AC Drive Reducer (PN.203010003061)
Electric motor
Rated voltage
16 V AC
Rated power
600 W
Rated speed
1205 r/min
Rated output torque 4.7 Nm (3.5 ft-lb)
Reducer
Rated output torque 500 Nm (368.5 ft-lb)
Reduction ratio 1:51.1
Brake
Rated voltage
24 V DC
Rated power
28 W
Rated torque ≥20 Nm (14.7 ft-lb)
Table 3-4 AC Drive Reducer (PN.203010003062)
Electric motor
Rated voltage
16 V AC
Rated power
0.6 kW
Rated speed 1395 rpm
Rated output torque 4.3 Nm (3.2 ft-lb)
Reducer
Rated output torque 190 Nm (140 ft-lb)
Reduction ratio 1: 45.13
Brake
Rated voltage
24 V DC
Rated power
30 W
Rated torque 25 Nm (18.5 ft-lb)
Table 3-5 AC Drive Reducer (PN.203010003068)
Electric motor
Rated voltage
16 V AC
Rated power
0.6 kW
Rated speed 1205 rpm
Rated output torque 4.7 Nm (3.5 ft-lb)
Table 3-5 AC Drive Reducer (PN.203010003068)
(continued)
Reducer
Rated output torque 214 Nm (158 ft-lb)
Reduction ratio 1: 45.13
Brake
Rated voltage
24 V DC
Rated power
28 W
Rated torque ≥20 Nm (14.7 ft-lb)
Battery
Table 3-6 Lead-acid Battery (PN.203100003090)
Model 3–DF-200
Rated voltage
6 V
Rated capacity (at room
temperature of 25℃)
200 Ah (5 hr)
Voltage at end of discharge
by 80%
5.25 V
Charging curve code
165 (Longsheng
charger)
303 (Tuobang charger)
22 (Yiyuan charger)
Table 3-7 Maintenance-free Lead-acid Battery
(PN.203100000017)
Model EVGC6A-A
Rated voltage
6 V
Rated capacity (at room
temperature of 25℃)
200 Ah (10 hr)
170 Ah (3 hr)
Standard charge current
60 A
Voltage at end of discharge
by 80%
5.7 V
Charging curve code
b04 (Longsheng
charger)
146 (Tuobang charger)
27 (Yiyuan charger)
