Table 12-1 Inspection and Preventive Maintenance Schedule (continued)
Item
Interval
Before each
delivery
1
or quarterly
2
Semiannually
3
Annually
4
Chassis wear pads (at the
connection with scissor arm)
1, 2, 5 1, 2, 5 1, 2, 5, 8
Tires
1, 2 1, 2 1, 2
Wheel nuts 1
50
1
50
1
50
Traveling and steering components
1, 2, 5 1, 2, 5 1, 2, 5
Bearings
1, 2, 5, 11 1, 2, 5, 11 1, 2, 5, 11
Chassis door at both sides
1, 2, 3 1, 2, 3 1, 2, 3
Ladder
1, 2, 5 1, 2, 5 1, 2, 5
Drive motor
1, 5, 6 1, 5, 6 1, 5, 6
Brake and brake release device
1, 5, 6 1, 5, 6 1, 5, 6
Electrical system
Electrical harness, connectors 1, 2 1, 2 1, 2
Battery
1, 2, 6, 9, 11 1, 2, 6, 9, 11 1, 2, 6, 9, 11
Electrolyte
6 6 6
Charging function
3 3 3
Electric actuator
1, 2, 3, 5, 6, 11 1, 2, 3, 5, 6, 11 1, 2, 3, 5, 6, 11
Instruments, gauges, switches,
lamps, horn
1, 3 1, 3 1, 3
Functions and controls
Platform controller
1, 3, 4, 7, 10 1, 3, 4, 7, 10 1, 3, 4, 7, 10
Ground controller
1, 3, 4, 7, 10 1, 3, 4, 7, 10 1, 3, 4, 7, 10
Function control lock, secondary
guarding device and brake
1, 3, 10 1, 3, 10 1, 3, 10
Emergency stop button (ground and
platform)
1, 3, 10 1, 3, 10 1, 3, 10
Limit switches and power switch
1, 3, 10 1, 3, 10 1, 3, 10
Overload limit function
1, 3, 10 1, 3, 10 1, 3, 10
Tilt alarm
1, 3, 10 1, 3, 10 1, 3, 10
Pothole protection device
1, 3, 10 1, 3, 10 1, 3, 10
Emergency lowering device
1, 3, 10 1, 3, 10 1, 3, 10
Drive function
1, 3, 10 1, 3, 10 1, 3, 10
Brake function
1, 3, 10 1, 3, 10 1, 3, 10
Other
Operation Manual in the manuals
compartment
10 10 10
