M300 Plus GNSS Receiver User Guide
26
3. Ntrip Caster
M300Plus can also work as a single reference station and send correction data
through Ntrip Caster protocol. You need to configure both Ntrip Server and Ntrip
Caster when you use this protocol. The setting is shown below:
1. Configuration of Ntrip Server:
Enable Active button of Ntrip Server
Set the Ntrip Caster address and Nrtip Caster port; this IP address is the same
as M300Plus IP address, and the port should be mapped by router.
Enter custom username and password
Access point: the Ntrip Caster mount point
Press Enter to save the configuration
2. Configuration of Ntrip Caster:
Enable Active button of Ntrip Caster
Enter port, this port should be same with Ntrip Server
Enter Username and Password, this Username and Password should be also
same with Ntrip Server
Press Enter to save configuration
All configurations of Ntrip Caster Protocol are shown above, then you can use a rover
to get correction data.
