1.2.2 Ports on A8 mini
Mark
The early manufacturing lots of A8 mini may not support 6S input, please refer to the
product sticker and carefully use.
DP / DM / RX- / RX+ / TX- / TX+ / GND / CVBS / NC
3S-6S / 3S-6S
/ GND / GND
