A8 mini User Manual v1.5

3.8 Necessary Trouble Shooting Steps When Gimbal Attitude

Control Is Abnormal

Let’s take an example of the problem that gimbal roll axis tilts abnormally.

Gimbal Roll Axis Tilts

Check Firmware

Version

Firmware Updated

PROBLEM SOLVED

Calibrate Gimbal

1. IMU

2. Temperature

3. Accelerator

Optimize Installation

1. Gimbal Mounting

2. Gimbal connection cables to power,

Ethernet, and control should be soft.

3. Are dampers original?

4. Check drone vibration and propeller

dynamic balance.

Firmware Updated

PROBLEM STILL

Calibrated

PROBLEM STILL

Calibrated

PROBLEM SOLVED

PROBLEM STILL
