SIYI A8 mini - 1.3 Technical Specification

A8 mini User Manual v1.5
11
2023 SIYI Technology Co., Ltd, All Rights Reserved
1.3 Technical Specification
Overall
Video Output Port
Ethernet, HDMI, CVBS(AV)
Control Signal Input
Port
S.Bus, UART, Ethernet UDP
Control Signal Output
Port
S.Bus
High Accuracy
3 Axis Stabilization
Yaw, Pitch, Roll
Working Voltage
11 ~ 25.2 V
(Early manufacturing lots may not support 25.2V, please be
careful)
Power Consumption
Average 5 W
Summit 12 W
Working Temperature
-10 ~ 50 ℃
Dimension
55 x 55 x 70 mm
Weight
95 g
Gimbal
Angular Vibration Range
±0.01°
Controllable Pitch Angle
-135° ~ +45°
Controllable Yaw Angle
-160° ~ +160°
Rotatable Roll Angle
-30° ~ +30°
Camera
Lens
Fixed Focal Length
6X Digital
Equivalent Focal Length
21 mm
Image Sensor
Sony 1/1.7-inch, 8 MP effective resolution
