1.5 Indicator Definition
The status indicator on SIYI gimbal uses three different colors and different blinking
frequencies to indicate the system’s working or abnormal status.
Solid Green: Normally working.
Slow Green Blinks: S.Bus signal input is normal.
Slow Red Blinks: Firmware does not match (camera firmware or gimbal firmware or
neither).
Red-Red-Yellow Blinks Continuously: Fail to identify camera board.
Yellow Blinks: Power input voltage is low (lower than 10 V).
Double Red Blinks: IMU temperature rising is abnormal.
Double Yellow Blinks: IMU temperature is rising.
Triple Yellow Blinks: IMU temperature is abnormal.
