1.2.2 Button / Switch Types and Default Channel Definitions
MK32E ground station comes with 16 physical channels and 16 communication
channels in total. Communication channels 10 to 14 are mapped to PWM
channels 1 to 5 in default.
Channel
No.
Physical Channel Type
Default Mapping
Remark
1
Aileron
Joystick J1
2
Elevator (Mode 2)
Joystick J2
3
Throttle (Mode 2)
Joystick J3
4
Rudder
Joystick J4
5
3-Stage Switch SA
6
3-Stage Switch SB
7
3-Stage Switch SC
8
3-Stage Switch SD
9
3-Stage Switch SE
10
3-Stage Switch SF
PWM 1
11
Left Dial LD1
PWM 2
12
Right Dial RD1
PWM 3
13
Left Dial LD2
PWM 4
14
Right Dial RD2
PWM 5
15
Searchlight A
Gimbal Pitch
Button S1
16
Searchlight B
Gimbal Centering
Button S2
