1.7 Indicator Definition
The status indicators on MK32E ground unit and air unit use three different colors
and different blinking frequencies to indicate the system’s working or abnormal
status.
1.7.1 Transmitter Indicator
Solid Red: No communication between ground unit and air unit.
Fast Red Blinks: Ground unit is binding to air unit.
Slow Red Blinks: Firmware does not match.
Triple Red Blinks: Link initialization failed.
Four-time Red Blinks: Joysticks require calibration.
Red-Green Blinks: Unexpected stop of Android system.
Red-Green-Yellow Blinks: Link is starting.
Slow Yellow Blinks: Ground unit power voltage abnormal.
Double Yellow Blinks: Ground unit Bluetooth is not identified.
Four Yellow Blinks: Ground unit Android system is in file transferring mode
through the Type-C port.
Yellow-Red Blinks: Ground unit high-temperature alert, level one.
Yellow-Red-Red Blinks: Ground unit high-temperature alert, level two.
Yellow-Red Blinks: Ground unit high-temperature alert, level three.
Solid Green: Perfect communication, receiving 100% data package.
