Air Unit HDMI Input Converter

(Optional, Packed with HDMI Combo)

Video Input

Mini HDMI

Video Output

Ethernet

Working Voltage

12 V

Power Consumption

3 W

Video Recording

Resolution

1080P (1920*1080) @ 30 fps

720P (1280*720) @ 30 fps

Recording Bitrate

12 Mbps

Storage Format

FAT32

Video Recording Format

H265

Supported TF / SD Card

Type

MicroSD Class10

Less than 32GB

Dimensions

42 x 41 x 11 mm

Weight

26 g

Working Temperature

-10℃ ~ 50℃
