2.2.2 Button/Switch Types and the Default Channel Definitions
VD32 transmitter has 16 channels in total. Each channel is controlled by an
independent switch or button. Please refer to the form below for the default
channel definitions from channel 1 to 16.
CH
Joysticks /
Buttons /
Switches
Default Definition:
Mode 2
JIYI FC
Notes
1
Joystick J1
Aileron
2
Joystick J2
Elevator (Reversed)
3
Joystick J3
Throttle
CH (-95, 95) *Standard E.S.C
CH (-89, 89) * FOC E.S.C
4
Joystick J4
Rudder
5
3-stage Switch
SA
Flight Mode
High: Attitude
Middle: GPS
Low: Execute AB
(Reversed)
6
3-stage Switch
SB
Return to Home,
Break Point
High: Off
Middle: Break Spraying
Low: Return to Home
(Reversed)
7
3-stage Switch
SC
Pump
Left: Off
Middle: Linkage
Right: Manual
(Reversed)
8
3-stage Switch
SD
A/B Point
High: Off
Middle: Record A
Low: Record B
(Reversed)
