MAINTENANCE PROCEDURES
mmo2009-004-028_b
TYPICAL
1. Coolant tank
Recommended Engine Coolant
Always use ethylene-glycol antifreeze
containing corrosion inhibitors specifi-
cally for internal combustion aluminum
engines.
Cooling system must be filled with
BRP PREMIXED COOLANT (P/N 219
700 362) or with distilled water and an-
tifreeze solution (50% distilled water,
50% antifreeze).
EngineOil (600 ACE)
Recommended Engine Oil
ENGINE
RECOMMENDED
ENGINE OIL
600 ACE
XPS 4-STROKE
SYNTHETIC OIL (ALL
CLIMATE) (P/N 293
600 112)
NOTICE
The engine of this snow-
mobile has been developed and val-
idated using the BRP XPS™ Synthe-
tic 4-stroke oil. BRP strongly recom-
mends the use of its XPS Synthetic
4-stroke oil at all times. Damages
caused by oil which is not suitable
for the engine will not be covered by
the BRP limited warranty.
If the recommended oil is not available,
use SAE 0W40 synthetic-based oil that
meets or exceeds the requirements
for API service classification SM
Engine Oil Level Verification
NOTICE
Check level every 10
hours of use and refill if necessary.
Do not overfill. Operating the en-
gine with an improper level may
severely damage engine. Wipe off
any spillage.
Place vehicle on a level surface and
proceed as follows to check oil level:
1. Start engine and let it reach its nor-
mal operating temperature. Engine
is at normal temperature when rear
radiator gets warm, indicating that
the thermostat is open.
2. Let engine run at idle for 30 more
seconds.
3. Stop engine.
4. Remove the drive belt guard, re-
fer to
CONTROLS, INSTRUMENTS
AND EQUIPMENT
.
5. Remove dipstick from the filler tube,
then wipe it clean.
6. Completely insert dipstick in the
filler tube.
7. Remove dipstick and check the
oil level. Oil level should be be-
tween the MIN. and MAX. marks
as shown, add if necessary.
1
MAX.
MIN.
mmo2009-005-027_a
1. Oil level between MIN. and MAX.
_______________
67
