CONTROLS, INSTRUMENTS AND EQUIPMENT
mmo2008-003-013_j
C) Trip Hour Meter
Records vehicle running time when
the electrical system is activated since
it has been reset.
Press the SET (S) button to select trip
hour meter (HrTRIP) mode.
mmo2008-003-013_c
1. Trip hour meter (HrTRIP) mode
Press and hold the SET (S) button to re-
set.
mmo2008-003-013_j
D) Fuel Level
Bar gauge that continuously indicates
the amount of fuel left in the fuel t
ank.
mmo2008-003-020_a
FUEL LEVEL
1. Operating range
E) E-TEC Engine Storage Mode
Displays OIL when the storage mode
procedure is initiated.
13) Passenger (1+1) Seat
A 1+1 passenger seat is provided as
standard equipment.
WARNING
Any passenger must be able to
firmly lay is feet on the footrests
and keep his hands on the grab
handlesatalltimeswhenseated.
Respecting those physical crite-
ria is important to ensures that the
passenger is stable and to reduce
the risks of ejection.
Passenger Seat Removal
1. Push the latch tab in and lift-up the
rear of seat.
mmo2009-004-017_a
Step 1: Push tab
Step 2: Lift rear of seat
2. Slide seat rearward and set aside.
_______________
39
