Skipper DL2 User Manual

2018-05-28
Page 51 of 60
Installation DL2 Doppler Speed Log System
Electronic unit JB70 Dimentional drawings
114
IP22 approved mounting
50 60 50
127
181,5
48 59
Use self tapping screw ST3,5 DIN7985-C, or equal (The screw length depends on condition of the wall)
Holes in the mounting strip = Ø3,7 mm
Recommended min. free space 133,5"
Existing wallExisting wall
Screw M3,5 x 14 (10x)
Nut M3,5 Nut M3,5 (20x)
Drip protector
ZAA-01330 Drip plate for JB70
Alternative assembly
E F C
1
2
3
4
B A
3
2
1
5
C D
4
6
7
8
A B
Electronics AS
D
E
ISO2768m
1 : 3
Gen. tolerance
Eur. projection
As Parts
Material
2017.03.08
Checked by
ST 2017.03.08 Changed free space
from 50mm to 133,5 inch.
CN
Drwg. no. Name
GT 2017.03.10
Edition date
Sheet
00
Revision
JB70DXX-SA
Scale
JB70DXX-SA mounted at wall
1 of 1
Designed by - date
PC
A.Matre 2012.10.31
Approved by - date
