SJ3215, SJ3219, SJ3220, SJ3226, SJ4726, SJ4732, SJ4740 216380ACA
73
Fold the guardrails Section 6 – Procedures
WARNING
Fall hazard. Use the three points of contact
principle when you use the MEWP ladder to enter
or exit the platform. If you do not obey, there is a
risk of death or serious injury.
16. Use the MEWP ladder to exit the platform.
WARNING
Fall hazard. Use a stable elevated surface that
gives you a solid footing to fold or unfold the
guardrails. You must be at eye-level height (at
a minimum) to the mid-rail. You must have your
hands free to fold or unfold the guardrails from
the external side of the MEWP. If you do not obey,
there is a risk of death or serious injury.
17. Remove the lock-pins on the front-left mid-rail.
18. Remove the lock-pins on the center-left mid-rail.
19. Remove the lock-pin on the rear-left mid-rail.
20. Hold the vertical bar of the extension guardrail
with one hand, and then fold the left guardrail
with the other hand (refer to Figure 21 for hand
positions).
21. Install the lock-pins to lock the left mid-rail.
Figure 21 Left guardrail folded
22. Remove the lock-pins on the front-right mid-rail.
23. Remove the lock-pins on the center-right
mid-rail.
24. Remove the lock-pin on the rear-right mid-rail.
25. Hold the vertical bar of the extension guardrail
with one hand, and then fold the right guardrail
with the other hand. Refer to Figure 21 for hand
positions.
26. Install the lock-pins to lock the right mid-rail.
27. Remove the remaining lock-pins from the rear
mid-rail:
28. Hold the rear mid-rail with one hand, and then
fold the rear gate with the other hand. Refer to
Figure 22 for the hand positions.
29. Install the lock-pins to lock the rear mid-rail.
Figure 22 Rear gate folded
