Specifications and Features-A Section 7 – Technical Diagrams & Specications
7.4 Specications and Features-A
Model SJ85 AJ
Platform Size
Total platform length (outside)
2.44 m / 1.83 m
(96 in / 72 in)
Total platform depth (outside) 0.91 m (36 in)
Height
Working 28 m (91 ft)
Platform elevated 26 m (85 ft)
Drive driveable at all heights
Stowed 2.67 m (8 ft 9 in)
Length
Overall with platform
11.63 m (38 ft 2 in)
Width
Outside std. tires
2.49 m (8 ft 2 in)
Weight
With foam- lled tires
16, 465 kg (36, 300 lb)
Platform rotation 168 degrees
Horizontal reach 17.22 m (56 ft 6 in)
Wheelbase 2.84 m (9 ft 4 in)
Turret rotation 360 degrees continuous
Turret tailswing 0.86 m (2 ft 10 in)
Gradeability (torque equivalent to) 45%
Ground clearance under axle 0.33 m (13 in)
Turning Radius
Inside
4WD
3.05 m (10 ft)
Outside 6.22 m (20 ft 5 in)
System voltage 12 V DC
Battery
Type Lead/Acid
Cold cranking amperes 800 A
Operating Times
Main boom up 85 - 95 seconds (approx.)
Main boom down 85 - 95 seconds (approx.)
Riser up 25 - 35 seconds (approx.)
Riser down 25 - 35 seconds (approx.)
Fly boom extend 45 - 55 seconds (approx.)
Fly boom retract 35 - 45 seconds (approx.)
Jib up 20 - 30 seconds (approx.)
Jib down 15 - 25 seconds (approx.)
Turret rotate 95 - 130 seconds (approx.)
Platform rotate 10 - 20 seconds (approx.)
Driving Speeds
Drive speed (maximum-stowed) 4.8 km/h (3.0 mph)
Drive speed (maximum-elevated) 0.8 km/h (0.5 mph)
