Tire/Wheel Specifications Section 7 – Technical Diagrams & Specications
7.6 Tire/Wheel Specications
SJ85 AJ
Tire Size
Outrigger R4 18-625
0.47 m x 1.05 m (18.7 in x 41.2 in)
Type Foam- lled
Tire Ply Rating 16
Wheel Nuts Torque 373 Nm
SJ85 AJ
Total Capacity (High)
340 kg (750 lb)
3 Persons
Total Capacity (Low)
227 kg (500 lb)
2 Persons
Maximum Wind 12.5 m/s
Maximum Side Force 400 N
Tilt Cutout Setting 5 degrees x 5 degrees
7.7 Maximum Platform Capacities
7.8 Floor Loading Pressure
Model
Gross MEWP
Weight
Total MEWP Load
Wheel LCP OUP
kg lb kg lb kPa psi kPa psf
SJ85 AJ 16,805 37,050 7,500 16,500 1,179 171 17 355
• Gross MEWP Weight = Weight + platform capacity
• Gross MEWP Weight = Weight + platform capacity
• LCP – Locally Concentrated Pressure – is a measure of how hard the MEWP tire tread presses on the area in direct
contact with the oor. The oor covering (tile, carpet, etc.) must be able to withstand more than the indicated values above.
• OUP – Overall Uniform Pressure – is a measure of the average load the MEWP imparts on the whole surface projected
directly underneath it. The structure of the operating surface (beams, etc.) must be able to withstand more than the
indicated values above.
e
• Welder option will add approximately 158.8 kg (350 lb) to total MEWP weight and 79.4 kg (175 lb) to max. wheel load.
NOTE
The LCP or OUP that an individual surface can withstand varies from structure to structure and is generally
determined by the engineer or architect for that particular structure.
