Skytech 32ST2000 - Page 20

43ST2103 SMART LED TV
19
OPTICRJ45 VIDEO L - I N - R LNB IN RF(C/T2)
USB1 USB2
HDMI2HDMI1 HDMI3
EARPHONE
COMMON INTERFACE(CI)
1 2 3 4 5 6 7
RJ45
Optıc Digital Audio Output
Video Input
Audio Input (L)
Audio Input (R)
LNB Input
1
2
3
4
5
6
7
8
9
10
11
12
13
14
RF,C/T2 Antenna Input
HDMI Input 1
HDMI Input 2
HDMI Input 3
USB 2
USB 1
Headphone Input
CI Module Input
INPUT / OUTPUT INPUT / OUTPUT
8 9 10 13 1411-12
