44
GND
1
Current
2
HI-Limit
3
LO-Limit
4
Dwell
5
Offset
6
Frequency
7
Connect (ON/OFF)
Test Parameter Editing Commands
These commands are used to modify the test parameter within each step. These commands require a
parameter value to be included with the command. The companion query command will read the parameter.
The writing of the parameter requires that the unit not be included with the value, only the numeric value
should be included with the command. Also when the query commands are used the response will not
include the units characters. Many of the commands will function the same way for multiple test types
however the input range may be different and therefore used a different possible set of values.
COMMAND
NAME
TEST TYPES
VALUE
EA < value >
EA?
Edit Arc
ACW
DCW
1 - 9
EAD {1|0}
EAD?
Edit Arc Detect
ACW
DCW
1 =On, 0=Off
ECC {1|0}
ECC?
Edit Step Connect
ALL
1= On, 0=Off
EC < value >
EC?
Edit Current
GND
3.00 - 30.00A
EDE < value >
EDE?
Edit Delay
IR
0.0, 0.5 - 999.9s
0.0 = Continuous
EDW < value >
EDW?
Edit Dwell
ACW
DCW
GND
0.0, 0.5 – 999.9s
0.0, 0.5 – 999.9s
0.0, 0.5 – 999.9s
0.0 = Continuous
EF {1|0}
EF?
Edit Frequency
ACW
GND
1=60Hz, 0=50Hz
EH < value >
EH?
Edit HI-Limit
ACW
DCW
IR
GND
4320: 0.0 – 20,000uA
4520: 0.0 – 99,990uA
4320: 0.0 – 5,000uA
4520: 0.0 – 10,000uA
0 - 1000M
0 - 510m
