43
File Editing Commands and Companion Queries
The following commands are used to create or modify Test Setup Files.
COMMAND
DESCRIPTION
VALUE
FL <file number>
FL?
File Load
file number = 1-6
SS <step number>
SS?
Step Select
step number = 1-6
SAA
Step Add ACW test
SAD
Step Add DCW test
SAI
Step Add IR test
SAG
Step Add GND test
FL <file number>
Load a file from non-volatile memory into random access memory RAM.
SS <step number>
Selects the active selected step to load into RAM. The step must first be selected before any specific
parameters can be edited.
The parameter values should use complete text and not use the coded values that are associated with the
individual parameter setting commands. Such as "ON" and "OFF" and any toggle field that use words or
phrases like "OPEN", "CLOSE". The LS? companion command will also list all parameters in complete text as
they appear on the setting screen.
ACW
DCW
IR
1
Voltage
Voltage
Voltage
2
Max Limit
Max Limit
Max Limit
3
Min Limit
Min Limit
Min Limit
4
Ramp Up
Ramp Up
Delay
5
Dwell
Dwell
DUT Output (ON/OFF)
6
Frequency
DUT Output (ON/OFF)
Connect (ON/OFF)
7
DUT Output (ON/OFF)
Connect (ON/OFF)
8
Connect (ON/OFF)
