47
LS?
Lists all the Parameters for the individual step that is currently selected.
The response will be formatted as follows; <step, test, p1, p2, p3…> Where <step> is the step number, <test>
is the test type and <p1,p2> etc., indicates the parameters of the test.
LS <step number>?
Lists all the Parameters for the individual step indicated by step number = 1-30.
The response will be formatted as follows; <step, test, p1, p2, p3…> Where <step> is the step number,
<test> is the test type and <p1,p2> etc., indicates the parameters of the test. IEEE 488.2 Common
Commands
These commands are required by the IEEE-488.2 standard with the exception of *PSC, *PSC?. Most of these
commands are not available over the RS-232 bus except for the *IDN? command which can be used to retrieve
the tester identification information, and the four status reporting commands *ESR?, *ESE, *ESE? and *STB?.
COMMAND
NAME
DESCRIPTION
*IDN?
Identification Query
SLA, Model Number, Serial Number,
Firmware Revision
*RST
Reset Command
Resets 4320/4520
*TST?
Self-Test Query
00H=OK
01H=TEST EEPROM ERROR
*CLS
Clear Status Command
Clear Standard Event Status Register
Clear Service Request Register
*OPC
Operation Complete Command
When TEST command ok setting ESR BIT0 =1
*OPC?
Operation Complete Query
1 = TEST completed ok
0 = TEST in process
*WAI
Wait-to-Continue Command
*PSC {1|0}
Power-on Status Clear Command
1 = Power-on clear enable registers
0 = Power-on load previous enable registers
*PSC?
Power-on Status Clear Query
*ESR?
Standard Event Status Register Query
0 - 255
*ESE <value>
Standard Event Status Enable
Command
value = 0 - 255
*ESE?
Standard Event Status Enable Query
0 - 255
*STB?
Read Status Byte Query
BIT 0, 01H,(1) Operation Complete
BIT 1,02H,(2) Not Used
BIT 2,04H,(4) Query Error
BIT 3,08H,(8) Device Error
BIT 4,10H,(16) Execution Error
BIT 5,20H,(32) Command Error
BIT 6,40H,(64) Not Used
BIT 7,80H,(128) PROMPT
*SRE <value>
Service Request Enable Command
value = 0 - 255
*SRE?
Service Request Enable Query
0 - 255
