Smanos W600 - PIR Motion Detector

15
Door/ Window Sensors are set to ‘Normal Zone’ by default and are ideal for protecting
entry/exit points such as front and back doors and windows. When the system is
armed, and a sensor is triggered (Magnet separated from the Transmitter), a push
notication including the sensor name will automatically be sent to the registered users
and the hub internal siren will sound immediately.
Tamper Switch
The tamper switch (small black button on the backside) will activate an alarm condition
if any attempt is made to remove the sensor from its installed location.
Low Battery Indication
If the LED indicator ashes once per 3 seconds, the battery needs to be replaced as
soon as possible.
PIR Motion Detector
The motion detector is designed for use on interior walls and is set to Home Mode by
default. Whenever the sensor detects movement (only while the system is armed), a
push notication including the sensor name will automatically be sent to the registered
users, and the hub’s internal siren will sound immediately.
1
2
1.
Detection window
2.
Status indicator
3.
Test button
4.
Double-sided tape stick place
5.
Bracket slot
Tamper switch
Infrared sensor
Status indicator
Flash contentiously Self-testing
Flash once Intrusion is detected
Flash twice 3 minutes testing mode is nished, enters power saving
mode
