TT301 - Operation and Maintenance Instruction Manual
5.2
POTENTIAL SOURCE OF PROBLEM
Primary variable out of calibrated Span (Output current in 3.8 or 20.5
mA, XMTR mode only).
Temperature out of operating limits.
Temperature sensor damaged.
Input signal out of operating limits.
Sensor damaged.
Transmitter with false configuration.
PV out of range limits (see table).
Table 1 - Diagnostics with the Configurator
Troubleshooting with Transmitter
Symptom: NO LINE CURRENT
Probable Source of Trouble:
Transmitter Connections
Check wiring polarity and continuity.
Check for shorts or ground loops.
Power Supply
Check power supply output. The voltage at the TT301 terminals must be between 12 and 45 Vdc,
and the ripple less than 0.4V.
Electronic Circuit Failure
Check the main board for defect by replacing it with a spare one.
Symptom: NO COMMUNICATION
Probable Source of Trouble:
Terminal Connections
Check terminal interface connections.
Check if the interface is connected to the points [COMM] and [-] or in the line between the
transmitter and the load resistor.
Check if the interface is model IF2 (for HART Protocol).
Transmitter Connections
Check if connections are as per wiring diagram.
Check line resistance; it must be equal to or greater than 250 Ohm, between the transmitter and the
power supply.
Power Supply
Check output of power supply. The voltage at the TT301 terminals must be between 12 and 45V,
and ripple less than 0.4V.
Electronic Circuit Failure
Locate the failure by alternately replacing the transmitter circuit and the interface with spare parts.
Transmitter Address
In On Line Multidrop item check if the address is "0".
