TT301 – Operation and Maintenance Instruction Manual
6.4
Ordering Code
MODEL
TEMPERATURE TRANSMITTER
COD.
Local Indicator (1)
0
Without Indicator
1
With Digital Indicator
COD.
Mounting Bracket
0
1
Without Bracket
Carbon Steel Bracket
2
7
316 SST Bracket
Carbon Steel Bracket with 316 SST Fasteners
A
Flat, 304 SST bracket and 316 SST accessories
COD.
Electrical Connections
0
1
2
1/2 - 14 NPT (3)
1/2 - 14 NPT X 3/4 NPT (316 SST) - With adapter (4)
1/2 - 14 NPT X 3/4 BSP (316 SST) - With adapter (2)
3
A
B
1/2 - 14 NPT X 1/2 BSP (316 SST) - With adapter (2)
M20 x 1.5 (5)
PG 13.5 DIN (6)
Z
According to user´s notes
COD.
Housing Material (8) (9)
H0
H1
H2
Aluminum (IP/TYPE)
316 SST (IP/TYPE)
Aluminum for saline atmosphere (IPW/TYPEX) (10)
H3
H4
316 SST for saline atmosphere (IPW/TYPEX) (10)
Copper Free Aluminum (IPW/TYPEX) (10)
COD.
Identification Plate
I1
I3
FM: XP, IS, NI, DI
CSA: XP, IS, NI, DI
I4
I5
EXAM (DMT): Ex-ia; NEMKO: Ex-d
CEPEL: Ex-d, Ex-ia
I6
I7
Without Certification
EXAM (DMT): Group I, M1 Ex-ia
IE
NEPSI: Ex-ia
COD.
Tag Plate (7)
J0
J1
With tag, when specified (Default)
Blank
J2
User specification
COD.
Sensor Connection
L2
L3
L4
2-wire
3-wire
4-wire
LF
LB
Differential
Backup
COD.
PID Configuration
M0
With PID (default)
M1
Without PID
COD.
LCD1 Indication
Y0
Y1
Percentage (default)
Current (mA)
Y3
YU
Temperature (Engineering unit)
User specification
COD.
LCD2 Indication
Y0
Y4
Percentage (default)
Current (mA)
Y6
YU
Temperature (Engineering unit)
User specification
COD.
Painting
P0
P3
P4
P5
Gray Munsell N 6,5 Polyester
(Default)
Black Polyester
White Epoxy
Yellow Polyester
P8
P9
PC
Without Painting
Safety Blue Epoxy – Electrostatic Painting
Safety Blue Polyester -
Electrostatic Painting
COD.
Sensor Type
T1
T2
T3
T4
T5
T6
T7
T8
T9
TA
TB
TC
TD
TE
TF
TG
TH
RTD Cu10 - GE
RTD Ni120 - DIN
RTD PT50 - IEC
RTD PT100 - IEC
RTD PT500 - IEC
RTD PT50 - JIS
RTD PT100 - JIS
2K OHM
400 OHM
Thermocouple type B - NBS
Thermocouple type E - NBS
Thermocouple type J - NBS
Thermocouple type K - NBS
Thermocouple type N – NBS
Thermocouple type R - NBS
Thermocouple type S - NBS
Thermocouple type T - NBS
TK
TP
TN
TO
TQ
TR
TS
TT
TU
TV
TW
TX
10
11
12
13
TZ
Thermocouple type L – DIN
Thermocouple type U - DIN
100 OHM
Special OHM
22 mV
100 mV
500 mV
Special mV
RTD PT1000 – IEC
RTD PT100 - MILT
RTD NI120 – MILT
RTD PT100 – IEC
RTD PT100 – GOST
RTD PR50 – GOST
CU100 – GOST
CU50 – GOST
Especial
TT301
1
2
0
H1
I1
JO
L2
M0
Y0
Y0
P8
T1
NOTE
(1) Values limited to 4 1/2 digits; units limited to 5 characters.
(2) Options not certified for use in hazardous locations.
(3) Certified for use in hazardous locations (CEPEL, CSA, FM, NEMKO, EXAM)
(4) Certified for use in hazardous locations (CEPEL, CSA, FM)
(5) Certified for use in hazardous locations (CEPEL, FM, NEMKO, EXAM)
(6) Certified for use in hazardous locations (CEPEL, NEPSI, EXAM)
(7) Rectangular plate in 316 SST.
(8) IPX8 tested in 10 meters of water column for 24 hours.
(9) Ingress Protection:
Products
CEPEL
NEMKO / EXAM
FM
CSA
NEPSI
TT300
IP66/68W
IP66/68W
Type 4X/6(6P)
Type 4X
IP67
(10) IPW/Type tested for 200 hours according to NBR 8094 / ASTM B 117 standard.
