Maintenance Procedures
5.5
NOTE
For housing in aluminium there is an insert in the position 15. This insert is used to improve the
grounding.
ACCESSORY
ODERING CODE
DESCRIPTION
SD-1
Magnetic Tool for local adjustment.
Palm*
16 Mbytes Palm Handheld, Including HPC301’s initialization and installation software.
HPC301*
HART® HPI311-M5P for the Palm, including the configuration package for the Smar and generic transmitters.
HPI311-M5P*
HART® interface.
* For equipment updates and HPC301 software, just check: http://www.smarresearch.com.
SPARE PARTS LIST FOR TRANSMITTER
DESCRIPTION OF PARTS
POSITION
CODE
CATEGORY
(NOTE1)
HOUSING, Aluminum (NOTE 2)
. See Housing Ordering Code
11
HOUSING, 316 SS (NOTE 2)
. See Housing Ordering Code
11
COVER
. See Cover Ordering Code
1 and 18
COVER WITH WINDOW FOR INDICATION
. See Cover Ordering Code
1
COVER LOCKING SCREW
10
204-0120
EXTERNAL GROUND SCREW
15
204-0124
IDENTIFICATION PLATE FIXING SCREW
13
204-0116
DIGITAL INDICATOR
3 and 4
400-0559
TERMINAL HOLDER INSULATOR
14
214-0220
BOARD GROUP GLL1403 AND GLL1436 (DISPLAY AND ASSEMBLY KIT INCLUDED); TT301.
5, 6, 7, 8
and 9
400-1300
A
BOARD GROUP GLL1403 AND GLL1436 (DISPLAY AND ASSEMBLY KIT NOT INCLUDED); TT301.
5, 6, 7, 8
and 9
400-1301
A
BOARD GROUP GLL1403 AND GLL1436 (WITHOUT DISPLAY AND WITH ASSEMBLY KIT INCLUDED); TT301.
5, 6, 7, 8
and 9
400-1302
A
BOARD GROUP GLL1403 AND GLL1436 (INCLUDED DISPLAY AND WITHOUT ASSEMBLY KIT); TT301.
5, 6, 7, 8
and 9
400-1303
A
ASSEMBLY KIT OF THE GROUP GLL1403 AND GLL1436; TT301
5, 7 and 8
400-1304
A
0-RINGS Cover, BUNA-N (NOTE 3)
2
204-0122
B
TERMINAL HOLDING SCREW
17
204-0119
CONDUIT PLUG
1/2 NPT Internal Socket Set Plug in Bichromatized Carbon Steel
16
400-0808
1/2 NPT Internal Socket Set Plug in 304 SST
16
400-0809
M20 X 1.5 External Socket Set Plug in 316 SST
16
400-0810
PG 13.5 External Socket Set Plug in 316 SST
16
400-0811
MOUNTING BRACKET FOR 2" PIPE MOUNTING (NOTE 4)
. Carbon Steel ( Accessories in Carbon Steel )
-
214-0801
. Stainless Steel 316 (Accessories in Stainless Steel 316 )
-
214-0802
. Carbon Steel ( Accessories in Stainless Steel 316 )
-
214-0803
LOCAL ADJUSTMENT PROTECTION CAP
12
204-0114
NOTE
1 - For category A, it is recommended to keep, in stock, 25 parts installed for each set, and for category B, 50.
2 - It includes terminal holder insulator, bolts (cover lock, grounding and terminal holder insulator) and identification plate without certification.
3 - 0-Rings are packaged in packs of 12 units.
4 - Including U-clamp, nuts, bolts and washers.
