This appendix provides information on integrating the SMARTBoard interactive whiteboard
system with peripheral devices.
Video format
The projector has a native video format and various video format compatibility modes. You can
change image appearances for certain formats and compatibilities.
Native Video Format
The following table lists the native VESA RGB video formats for the projector.
Projector Resolution Mode Aspect ratio Refresh
rate
(Hz)
Horizontal
frequency
(kHz)
Pixel
clock
(MHz)
SMART U100 1024 × 768 XGA 4:3 60 48 65
SMART U100w 1280 × 800 WXGA 16:10 60 48 65
