APPENDIX A
REMOTELY MANAGING THE SYSTEM THROUGH A NETWORK INTERFACE
55 smarttech.com/kb/170910
Submenu setting Description
Video Mute Turns the video mute setting on or off. Select On to hide the display
and Off to show it again.
High Speed Fan Adjusts the speed of the projector’s fan. Select High or Normal.
NOTE
Use the High setting when the projector’s temperature is high or
the altitude is above 6000' (1800 m).
Projector Mode Adjusts the projection mode to Front, Ceiling, Rear or Rear Ceiling.
IMPORTANT
SMART recommends that you never change this setting from the
Ceiling projection mode.
Source Adjusts the input source to VGA1, HDMI1, HDMI2, or Composite.
HDMI1 Assigns an alternative name (up to 15 characters long) to the HDMI1
input, which appears when you select the HDMI1 input.
HDMI2 Assigns an alternative name (up to 15 characters long) to the HDMI2
input, which appears when you select the HDMI2 input.
VGA1 Assigns an alternative name (up to 15 characters long) to the VGA1
input, which appears when you select the VGA1 input.
Composite Assigns an alternative name (up to 15 characters long) to the
Composite video input, which appears when you select the
Composite video input.
Emergency Alert Turns the on-screen alert broadcast message on or off. When
enabled, this message displays over the current projected image.
Alarm Message Displays an on-screen emergency notification message (maximum
60 characters).
Network settings
This menu allows you to use or not use Dynamic Host Control Protocol (DHCP) and to set the
network-related addresses and names when DHCP isn’t used.
Submenu setting Description
DHCP Determines if the projector’s IPaddress and other network settings
are dynamically assigned by a DHCPserver or are manually set.
l
On allows the network’s DHCP server to assign a dynamic IP
address to the projector.
l
Off allows you to manually set the projector’s IP address and
other network settings.
