APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 22 of 54
No.
Items
Parameter
Default
Description
10
Over
Speed
Shutdown
Set
Value
(0-1000)%
114
Setting value is percentage of rated speed,
and return value and delay value can be set.
Delay
(0-3600)s
2
11
Under
Speed
Shutdown
Set
Value
(0-1000)%
80
Delay
(0-3600)s
3
12
Loss of Speed
Signal Delay
(0-3600)s
5
Time from detecting speed is 0 to confirm the
action.
13
Loss of Speed
Action
(0-1)
0
0:Warning; 1:Shutdown
14
Battery Rated
Voltage
(0-60.0)V
24.0
Provide standard for judgment of over /under
voltage.
15
Bat. Over
Voltage
Warning
Set
Value
(0-1000)%
120
Setting value is percentage of rated voltage,
and return value and delay value can be set.
Return
Value
(0-1000)%
115
Delay
(0-3600)s
60
16
Bat. Under
Voltage
Warning
Set
Value
(0-1000)%
85
Return
Value
(0-1000)%
90
Delay
(0-3600)s
60
17
Charge
Alt Fail
Set
Value
(0-60.0)V
8.0
In normal running, when charger D+ (WL)
voltage under this value, charge failure alarms.
Return
Value
(0-60.0)V
10.0
Delay
(0-3600)s
10
18
Engine Idle
(0-100)%
60
Setting value is percentage of rated speed,
and speed need to be stabilized at the setting
point while in idle running.
19
Suction Pump
Crank
(0-2)
0
0: Not used; 1: D-driven Suction Pump; 2:
E-driven Suction Pump
20
D-driven Suction
Pump Fault
Shutdown Delay
(0-3600)s
90
It is time waiting for pressure to suction pump
(input port is active).
21
E-driven Suction
Pump Shutdown
Outlet Pressure
(0-1000)kPa
100
It is the value of stopping output crank E-driven
suction pump.
Module
1
Power On Mode
(0-2)
0
0: Stop Mode; 1: Manual Mode; 2: Auto Mode
2
Module Address
(1-254)
1
Controller’s address during remote sensing.
3
Stop Bits
(0-1)
0
0: 2 stop bits; 1: 1 stop bit (PC software
setting)
4
Password
(0-65535)
00318
For entering advanced parameters setting.
