SDRe Programming Software
Press on the side arrow to change it if you want. Possible values:
12.5 KHz.
Once selected the right parameter, press [Ok] to save it or [Cancel]
to exit.
5.5.1.9. Channel mode selection
This option lets you assign existing signaling profile and
modulation type for the current channel.
Figure 88: Channel mode selection
Once selected the right parameter, press [Ok] to save it or [Cancel]
to exit.
5.5.1.10. Channel Profile Selection:
The right profile, previously defined on 4.6.1 or 4.6.2., must be
attached to the current channel by pressing the side arrow on
the Profile Field.
A list the pre-defined profiles will be listed.
Figure 89: type of modulation
Click over the right one to select it.
Once selected the right parameter, press [Ok] to save it or [Cancel]
to exit.
