-88-
No.PF※※-OMY0005
1: "R" means Read and "W" means Write.
2: Refer to the table below for the symbol.
Symbol
Data type
(IO-Link standard)
Data length
Bit [byte]
Description
U8
UIntegerT
8[1]
Unsigned integer
U16
16[2]
S16
IntegerT
16[2]
Signed integer
F32
Float32T
32[4]
Floating point number
3: "Y" indicates that the parameter setting data is saved to the master, and "N" indicates that the parameter is not saved.
4: Read/write to un-selectable items will be rejected depending on the product No.
[Toggle output command]
Item
Value
Notes
Measured value
Accumulated
0
Connected with hardware output
(Since OUT1 is IO-Link communication,
only the indicator light is linked.)
Flow rate
1
Temperature
2
Pressure
3
OUT output bit
OUT1
16
Reverse only the bits of the process data.
Even if the bit is the object of OUT output, it does not
affect the OUT output and indicator light.
OUT2
17
SW output bit
Accumulated 1
32
Connected with hardware output
(Not connected as OUT2 does not have the hardware)
Accumulated 2
33
Flow rate 1
34
Flow rate 2
35
Temperature 1
36
Temperature 2
37
Pressure 1
38
Pressure 2
39
Pulse output 2
65
This is valid only when the output object of OUT2 is
pulse output.
Display unit bit
208
Unit reference bit
209
s
Flow diagnosis bit
224
Temperature diagnosis bit
225
Pressure diagnosis bit
226
Error bit
254
System error bit
255
