[Data for sub screen]
Value
Setting content
Supplemental information
0
Measurement display
Initial value
1
OUT1
set
value
display
Flow rate HYS mode set value
Values that do not match the OUT output
mode settings can also be written. In this
case, there is a contradiction in the display
of the sub screen.
2
Flow rate HYS mode hysteresis
3
Flow rate Wind mode lower side set value
4
Flow rate Wind mode upper side set value
5
Flow rate Window comparator mode hysteresis
6
Temperature HYS mode set value
7
Temperature HYS mode hysteresis
8
Temperature Wind mode lower side set value
9
Temperature Wind mode upper side set value
10
Temperature Wind mode hysteresis
11
Pressure HYS mode set value
12
Pressure HYS mode hysteresis
13
Pressure Wind mode lower side set value
14
Pressure Wind mode upper side set value
15
Pressure Wind mode hysteresis
16
AC mode set value
17
PLS mode set value
18
Err mode
19
oFF mode
20
OUT2
set
value
display
Flow rate HYS mode set value
21
Flow rate HYS mode hysteresis
22
Flow rate Wind mode lower side set value
23
Flow rate Wind mode upper side set value
24
Flow rate Wind mode hysteresis
25
Temperature HYS mode set value
26
Temperature HYS mode hysteresis
27
Temperature Wind mode lower side set value
28
Temperature Wind mode upper side set value
29
Temperature Wind mode hysteresis
30
Pressure HYS mode set value
31
Pressure HYS mode hysteresis
32
Pressure Wind mode lower side set value
33
Pressure Wind mode upper side set value
34
Pressure Wind mode hysteresis
35
AC mode set value
36
PLS mode set value
37
Err mode
38
oFF mode
39
Flow bottom value
40
Flow peak value
41
Temperature bottom value
42
Temperature peak value
43
Pressure bottom value
44
Pressure peak value
45
IO-Link mode display
Upper line: SIO mode/SDCI mode
Lower line: Device ID
