C
ONSOLE
I
NTERFACE
4-44
Forward Delay Time – The maximum time (in seconds) the root
device will wait before changing states (i.e., listening to learning to
forwarding). This delay is required because every device must receive
information about topology changes before it starts to forward frames.
In addition, each port needs time to listen for conflicting information
that would make it return to a blocking state; otherwise, temporary data
loops might result.
-Default: 15
- Minimum: The higher of 4 or [(Max. Message Age / 2) + 1]
-Maximum: 30
Console – Click Protocol Related Configuration
=>
STP
=>
System
Configuration. Modify the required attributes, and save your settings
Tiger Switch 10/100 6709FL2 : STP System Configuration
===========================
Root Bridge Information Configure Spanning Tree Parameters
------------------------ -----------------------------------
Priority : 32768 Priority (1-65535) :32768
Mac Address : 0000ABCD0000
Root_Path_Cost: 10 Max Age (6-40) :20
Root Port : 2
Max Age : 20 Hello Time (1-10) :2
Hello Time : 2
Forward Delay : 15 Forward_Delay_Time(4-30) :15
actions-> <Edit> <Save> <Quit>
Select the action menu.
Tab=Next Item BackSpace=Previous Item Quit=Previous Menu Enter=Select Item
