M
AIN
M
ENU
3-5
VLAN Configuration 3-27
Basic Configures VLAN groups, including name,
identifier, and if limited to a specific protocol
3-28
3-29
Port VID Sets port VID and ingress filters 3-32
Spanning Tree Configures global bridge and port settings
for STP; also displays current port status
3-34
Port Sniffer Sets the source and target ports for mirroring 3-39
SNMP 3-40
System Options Provides basic system description, including
contact information
3-40
Community Strings Configures community strings 3-40
Trap Managers Sets trap management stations 3-41
Security Manager Assigns a user name and password 3-42
TFTP Update Firmware Downloads a new code image 3-43
Configuration Backup 3-44
TFTP Restore
Configuration
Restores configuration settings 3-44
TFTP Backup
Configuration
Backs up configuration settings 3-44
Reset System Resets switch to the default configuration 3-45
Reboot Reboots the switch 3-45
Menu Description Page
