-14-
PS##-OMM0003-A
Terms Meaning
Sampling cycle
The frequency in which the detected pressure should be reflected to the digital
indication.
Setting of function See "Function selection mode".
Setting pressure range The pressure range within which switch output can be set.
Stainless steel diaphragm
A stainless steel pressure-detecting part of the pressure-detecting element. It is
suitable for measuring fluid such as water.
S
Switch output Alternatively called "ON-OFF output".
T
TSJ fitting
Abbreviation for Tube Swage Joint. The recommended fitting is Swagelok fitting
made by Swagelok.
URJ fitting
Abbreviation for Union Ring Joint. The recommended fitting is VCR fitting made
by Swagelok.
U
Unit conversion function
Function to change the unit in which the value of pressure is indicated. Only a
product with this function can change the unit. A product with unit-changing
function cannot be purchased if it is used within Japan. Pressure is indicated only
by SI units in Japan.
Wetted part
(or part exposed to gas)
That part of the Pressure switch which is in contact with detected fluid such as a
pressure sensor, seal, and fitting.
Window comparator mode
An output type that holds the output when the pressure is within a certain range.
(Refer to "List of output mode" on page 28.)
W
Withstand voltage
Durability to voltage applied between an electric circuit and a body. A product's
durability in withstanding voltage. If more voltage is applied to the product, the
product may be broken. (Voltage mentioned here is not power voltage to activate
the product.)
Z
Zero clear (function) Adjusts the displayed pressure value to "0".
