-52-
PS##-OMM0003-A
Specification
■Specifications
Model No.
ISE80
(positive pressure)
ISE80H
(positive pressure)
ZSE80
(vacuum)
ZSE80F
(compound)
Rated pressure range -0.1 to 1 MPa -0.1 to 2 MPa 0 to –101 kPa -100 to 100 kPa
Set pressure range -0.105 to 1.1 MPa -0.105 to 2.2 MPa 10 to –111 kPa -110 to 110 kPa
Withstand pressure 2 MPa 4 MPa 500 kPa
Setting and display resolution 0.001 MPa
0.001 MPa
(1.999 MPa)
0.01 MPa
(2.00 to 2.20 MPa)
0.1 kPa
Port material Pressure sensor: SUS630, Fitting: SUS304
Fluid Fluid which has no corrosive effect on SUS630, SUS304
Connection port
R1/4, NPT1/4, G1/4
∗
, URJ1/4, TSJ1/4, Rc1/8
Piping direction: Rear or Bottom
Power supply voltage
12 to 24 VDC ±10%, ripple (p-p) 10% or less
(Protected against reverse connection)
Current consumption 45 mA or less
Switch output NPN1 output, NPN2 output, PNP1 output, PNP2 output
Max. load current 80 mA
Max. applied voltage 28 V (NPN output)
Residual voltage 1 V or less (80 mA load current)
Response time 2.5 ms (With anti-chatter function: 20, 100, 500, 1000, 2000 ms selectable)
Short circuit protection Provided
Repeatability ±0.2%F.S. ±1 digit
Hysteresis mode
Hysteresis
Window comparator mode
0 to variable
Output voltage
0.6 to 5 V
±2.5%F.S.
Linearity: ±1%F.S.
0.8 to 5V
±2.5%F.S.
Linearity: ±1%F.S.
1 to 5V
±2.5%F.S.
Linearity: ±1%F.S.
Voltage
output
Output impedance Approx. 1 kΩ
Output current
2.4 to 20 mA
±2.5%F.S.
Linearity: ±1%F.S.
3.2 to 20 mA
±2.5%F.S.
Linearity: ±1%F.S.
4 to 20 mA
±2.5%F.S.
Linearity: ±1%F.S.
Analogue
output
Current
output
Load impedance
Max. load impedance: 300 Ω (power supply voltage of 12 V)
: 600 Ω (power supply voltage of 24 V)
Min. load impedance: 50 Ω
Auto shift input
Non-voltage input (reed or solid state), Low level 0.4 V or less,
input times 5 ms or more
Display method 3 1/2 digits, 7-segment display, Dual-color display (red/green)
Display accuracy ±2%F.S. ±1 digit (ambient temperature 25±3
o
C)
Indicator OUT1/OUT2: ON when LED is ON (Orange)
Functions
Anti-chatter function, Zero clear, Key lock, Auto pre-set,
Display unit conversion, Power saving mode, Auto shift
∗: G1/4 is connected to the back only.
