SMC Networks ZSE80(F) User Manual

-33-
PS##-OMM0003-A
■[F 7] Setting of fine adjustment of display value
This is the function to perform fine adjustment of the displayed pressure manually.
It is adjustable within the range ±5%R.D.
<Operation>
Press the
or button in function selection mode to display [F 7].
Press the
button.
Move on to setting of display resolution.
Press the button to set.
Press the
button.
Move on to setting of adjustment initialize.
Press the
button to set.
Return to function selection mode.
Setting of [F 7] fine adjustment of display value completed
Setting of fine adjustment of display value
Press the
or button to change the set pressure.
Setting of initializing of adjustment
(for initializing adjusted value)
Press the
or button to select the initializing of
adjustment.
