-29-
PS##-OMM0003-A
■[F 2] Setting of OUT2
Set output method of OUT2.
Display color depends on OUT1 output, and is not set with this function.
<Operation>
Press the
or button in function selection mode to display [F 2].
Press the
button.
Move on to setting output mode.
Set based on [F 1] setting of OUT1 (page 26 to 28).
■[F 3] Setting of response time (Chattering prevention function)
Select the response time of the switch output.
Output chattering is prevented by setting the response time.
<Operation>
Press the
or button in function selection mode to display [F 3].
Press the
button.
Move on to setting of response time.
Press the
button to set.
Return to function selection mode.
Setting of [F 3] response time completed
Setting of response time
Press the
or button to select response time.
To Next Page
