-25-

PS##-OMM0003-A

■[F 0] Unit conversion function

This function is available for unit selectable type.

The unit that can be displayed is different depending on the pressure range.

(Refer to the table for the minimum indication unit below.)

(Display in kPa and MPa is available in ZSE80(F)/ISE80 series if unit conversion function is not

equipped.)

Press the

or button in function selection mode to display [F 0].

Press the

button.

Move on to unit conversion function.



Press the

button to set.

Return to function selection mode.

Setting of [F 0] unit conversion function completed

•Indication unit and minimum setting unit

Unit ZSE80F ZSE80 ISE80 ISE80H

MPa 0.001 0.001 0.001

0.001 (to 1.999)

0.01 (2.00 to)

kPa 0.1 0.1 1 -

kgf/cm

0.001 0.001 0.01

0.01 (to19.99)

0.1 (20.0 to)

bar 0.001 0.001 0.01

0.01 (to 19.99)

0.1 (20.0 to)

psi 0.01 0.01 0.1

0.1 (to 199.9)

1 (200 to)

InHg 0.1 0.1 - -

mmHg 1 1 - -

Select Indication Unit

Press the

or button to select the indication unit.
