23
Pin #
Signal Name
Description
B2
DIO0_CH2
ISP Channel 2: Digital input/output 0
B3
DIO1_GND_CH2
ISP Channel 2: Digital input/output 1 Ground
B4
DIO3_CH2
ISP Channel 2: Digital input/output 3
B5
DIO4_GND_CH2
ISP Channel 2: Digital input/output 4 Ground
B6
DIO6_CH2
ISP Channel 2: Digital input/output 6
B7
DIO7_GND_CH2
ISP Channel 2: Digital input/output 7 Ground
B8
RLY_ON_CH2
ISP Channel 2: Relay Barrier Driver Output
B9
RLY_ON_CH1
ISP Channel 1: Relay Barrier Driver Output
B10
VPROG0_GND_CH1
ISP Channel 1: Programmable voltage 0 Ground
B11
DIO0_CH1
ISP Channel 1: Digital input/output 0
B12
DIO1_GND_CH1
ISP Channel 1: Digital input/output 1 Ground
B13
DIO3_CH1
ISP Channel 1: Digital input/output 3
B14
DIO4_GND_CH1
ISP Channel 1: Digital input/output 4 Ground
B15
DIO6_CH1
ISP Channel 1: Digital input/output 6
B16
DIO7_GND_CH1
ISP Channel 1: Digital input/output 7 Ground
C1
VPROG1_CH2
ISP Channel 2: Programmable voltage 1
C2
DIO0_GND_CH2
ISP Channel 2: Digital input/output 0 Ground
C3
DIO2_CH2
ISP Channel 2: Digital input/output 2
C4
DIO3_GND_CH2
ISP Channel 2: Digital input/output 3 Ground
C5
DIO5_CH2
ISP Channel 2: Digital input/output 5
C6
DIO6_GND_CH2
ISP Channel 2: Digital input/output 6 Ground
C7
RESERVED_CH2
ISP Channel 2: Reserved Pin
C8
GND_RLY_CH2
ISP Channel 2: Relay Barrier Ground
C9
GND_RLY_CH1
ISP Channel 1: Relay Barrier Ground
C10
VPROG1_CH1
ISP Channel 1: Programmable voltage 1
C11
DIO0_GND_CH1
ISP Channel 1: Digital input/output 0 Ground
C12
DIO2_CH1
ISP Channel 1: Digital input/output 2
C13
DIO3_GND_CH1
ISP Channel 1: Digital input/output 3 Ground
C14
DIO5_CH1
ISP Channel 1: Digital input/output 5
C15
DIO6_GND_CH1
ISP Channel 1: Digital input/output 6 Ground
C16
RESERVED_CH1
ISP Channel 1: Reserved Pin
Table 5: ISP Connector Signals (Channels 3 and 4)
Pin #
Signal Name
Description
A1
VPROG0_CH4
ISP Channel 4: Programmable voltage 0
A2
VPROG1_GND_CH4
ISP Channel 4: Programmable voltage 1 Ground
A3
DIO1_CH4
ISP Channel 4: Digital input/output 1
A4
DIO2_GND_CH4
ISP Channel 4: Digital input/output 2 Ground
A5
DIO4_CH4
ISP Channel 4: Digital input/output 4
A6
DIO5_GND_CH4
ISP Channel 4: Digital input/output 5 Ground
A7
DIO7_CH4
ISP Channel 4: Digital input/output 7
A8
PWR_RLY_CH4
ISP Channel 4: Relay Barrier Power Source
