SMH Technologies FlashRunner LAN 2.0 - Physical and Environmental Specifications

39
6.4 Physical and Environmental Specifications
Table 17: Physical and Environmental Specifications
Parameter
Value
Dimensions, open frame version
140 x 60 x 18 mm
Dimensions, case version
140 x 70 x 18 mm
Dimensions, with relay barrier
-
“ISP” connectors type
48 way, 3 row, DIN 41612, pitch = 2.54mm (male)
“ATE CONTROL” connector type
14 way, 2 row, box header, pitch = 1.27mm (male)
“USB” connector type
USB-B micro receptable
“LAN” connector type
RJ-45 connector
“POWER” connector type
DC Plug
Operating temperature
0-50°C
Operating humidity
90% max (without condensation)
Storage temperature
0-70°C
Storage humidity
90% max (without condensation)
EMC (EMI/EMS)
CE, FCC
Sd card size
Up to 200 GB, by default mounts 2GB
